동축케이블
OCA67G for 67GHz
디자인특징
- Good Stability by Precision Core Technology
- High Shielding Effectiveness
- Typ. VSWR <1.30:1 @ 67 GHz (with V conn.)
- Cost Effectiveness & Loss Insertion Loss
- Lower Dielectric constant core by LD PTFE
- Anti-shock / Shock resistance Steel Armor Option
- Minimal Phase Change at Temp. and Bending
| Electrical Specification | |
|---|---|
| Operating Frequency | DC to 67 GHz |
| Impedance | 50±1 Ω |
| Velocity of Propagation | 77% |
| RF leakage | -100 dB |
| I/L Stability vs. Bending | ± 0.3dB /m @ 67GHz |
| Phase Stability vs. Bending | Max. 19 º @ 67GHz |
| Crush resistance (kg/cm) | 150 |
| Mechanical Specifications | |
|---|---|
| Center Conductor | Silver Plated Copper |
| Dielectric Material | LD PTFE |
| Jacket / Out Diameter | S-Spiral+T-fiber / 6.70mm |
| Temperature Range | -50 ~ +135 ℃ |
| Weight [g/m] | 190 |
| Minimum Bend Radius | 30 mm |
| Matched Connector | 2.92mm |
